Segment Trees
A segment tree is a heap-like data structure that can be used for making update/query operations upon array intervals in logarithmical time. We define the segment tree for the interval [i, j] in the following recursive manner:
- the first node will hold the information for the interval [i, j]
- if i<j the left and right son will hold the information for the intervals [i, (i+j)/2] and [(i+j)/2+1, j]
See the picture below to understand more :
We can use segment trees to solve Range Minimum/Maximum Query Problems (RMQ). The time complexity is T(N, log N) where O(N) is the time required to build the tree and each query takes O(log N) time. Here’s a C++ template implementation :
#include<iostream> using namespace std; #include<math.h> template<class T> class SegmentTree { int *A,size; public: SegmentTree(int N) { int x = (int)(ceil(log2(N)))+1; size = 2*(int)pow(2,x); A = new int[size]; memset(A,-1,sizeof(A)); } void initialize(int node, int start, int end, T *array) { if (start==end) A[node] = start; else { int mid = (start+end)/2; initialize(2*node,start,mid,array); initialize(2*node+1,mid+1,end,array); if (array[A[2*node]]<= array[A[2*node+1]]) A[node] = A[2 * node]; else A[node] = A[2 * node + 1]; } } int query(int node, int start, int end, int i, int j, T *array) { int id1,id2; if (i>end || j<start) return -1; if (start>=i && end<=j) return A[node]; int mid = (start+end)/2; id1 = query(2*node,start,mid,i,j,array); id2 = query(2*node+1,mid+1,end,i,j,array); if (id1==-1) return id2; if (id2==-1) return id1; if (array[id1]<=array[id2]) return id1; else return id2; } }; int main() { int i,j,N; int A[1000]; scanf("%d",&N); for (i=0;i<N;i++) scanf("%d",&A[i]); SegmentTree<int> s(N); s.initialize(1,0,N-1,A); while (scanf("%d%d",&i,&j)!=EOF) printf("%d\n",A[s.query(1,0,N-1,i-1,j-1,A)]); }
Resources:
NJOY!
-fR0D
Hey, nice tut. If u add a tutorial for updating the values in segment tree, it will be great!
Boris
September 18, 2010 at 12:34 PM
when i five n= 800 in input then this code crashes.
please help
Anuj
October 13, 2010 at 8:53 AM
please add the nessary discription about n,A[i]. and also add the necassary printf statements . please reply immediately
berin
November 12, 2010 at 7:22 PM
Do you think this guy’s your slave or what?
Andrés Mejía
November 14, 2010 at 8:55 PM
could u plzzz add a good tutorial on binary indexed tree as they r easy to code????
aayush kumar
June 9, 2011 at 4:49 PM
There already is a post on that https://comeoncodeon.wordpress.com/2009/09/17/binary-indexed-tree-bit/
fR0DDY
June 9, 2011 at 8:30 PM
Hi I Don’t Understand Whats the application of segment tree ? i mean if we can search the element in given range of sorted array in O(logn) then why we need such complex DS or m i missing sum-thing so do u mean we can find the elements in unsorted array in O(logn) is it so .?? as Heap can unsorted array as 5 4 3 1 2 isn’t it .?? also please explain the in detail the initialize & query part & also write update part as you have mentioned..i am really interest in algorithms & so i wants to know what we can do with segment tree once you will reply my question i will really look & analyze it…i mean really really interested & appreciate ur attempt.
i mean when i m giving input for i & j 0 ,5 or i=0 & j=1 to 9 for N=10 array then i am getting output of query is 0 m not getting what exactly query function is doing ?? whats the purpose of it does it s giving element in range or its searching particular element & returning that element.
Reply ASAP.
Algoseekar
June 12, 2011 at 10:08 PM
It can be used to find maximum/minimum element in a range of an unsorted array. Also between the queries also, you can update any element.
fR0DDY
June 15, 2011 at 10:27 PM
Bugs in the code above.
-> log is logarithm to the base 10, whereas log to the base 2 should be used.
-> only the position should be returned in line numbers 50,52,55,57.
To verify the bug run the code with the following input
N = 8
array = { 1, 2, 0, -1, 5, 5, 5, 5 }
first i,j -> 1 2 ( gives correct output of 0 )
second i,j -> 3 4 (gives incorrect output of 0)
mozzak
October 1, 2011 at 12:43 PM
This is the output for this case- remember output is minimum element 🙂
8
1 2 0 -1 5 5 5 5
1 2
1
3 4
-1
shashank jain
August 2, 2012 at 7:25 PM
It would be better if in the tree initialization N = 2^X, you would get faster solution. Your current solution would get TL on some test cases… I don’t remeber testcases, but I promise you that N should be equal 2^x 🙂
vilvler
February 27, 2012 at 3:02 PM
Why would it be faster if you are adding more nodes to the tree?
Andrés Mejía
February 28, 2012 at 5:38 AM
Nice tutorial, I also wanted to know about updation of segment trees. How is it achieved? Can you explain a little more?
aman
June 18, 2012 at 8:54 AM
hey how to implement if i need all intervals with 0<=i<j<n
like for eg in the above tree i need to fint the max from the interval [1,8]
aichemzee
December 9, 2012 at 2:55 AM
I beleive the time complexity of construction the segment tree is $O(n\log n)$.
Macropodus
February 23, 2013 at 9:51 PM
There’s a small bug, not so important yet proves pain in neck if tested under certain input ranges. For very large range say 1 to 100000. The Query function goes so deep in recursion that it exceeds the recursion depth & hence will result as “Segmentation Fault”. I’ve tried it locally on my machine and on online competition too to verify.
Ravi Ojha
May 12, 2013 at 1:59 PM
[…] wcipeg.com/wiki/Segment_tree comeoncodeon.wordpress.com/2009/09/15/segment-trees/ letuskode.blogspot.com/2013/01/segtrees.html […]
Segment Trees | Sport CoderSport Coder
December 5, 2013 at 1:25 AM
[…] en.wikipedia.org/wiki/Segment_tree wcipeg.com/wiki/Segment_tree comeoncodeon.wordpress.com/2009/09/15/segment-trees/ letuskode.blogspot.com/2013/01/segtrees.html p–np.blogspot.com/2011/07/segment-tree.html […]
Segment Trees - Lazy Updates
December 10, 2013 at 10:03 PM
hey it fails to be in ti,e limit if no of queries ranges to 10^8…… some more better approach required …..
